easy chain® - Very easy to fill - simply push in cables

easy chains are available in two versions. In the "E" version the cable is simply installed from the outside, and in the "Z" version from the inside. The primary reason for choosing easy chain energy chains is to save time when fitting cables. The igumid NB material presents more application opportunities due to its flexibility, UL94-V2 classification and excellent cleanroom qualities. The one-piece design keeps the easy chain very cost-effective. Due to the low inherent rigidity of the material, the easy chain is not suitable for applications involving very high loads.

Order a free sample now

Your advantages:

  • Easy to fill
  • Cost-effective
  • Quiet operation:
  • High acceleration rates
Further benefits at a glance

Version "E" can be filled from the outside

E03 series

Series E03

inner height hi: 5mm
inner width Bi: 5 - 10mm
bend radius R: 10 - 28mm
pitch: 10mm

e-chain®, to be filled in the outer radius
Series E04

Series E04

inner height hi: 7mm
inner width Bi: 7mm
bend radius R: 15 - 48mm
pitch: 16.7mm

e-chain®, to be filled in the outer radius
Series E08

Series E08

inner height hi: 14.6mm
inner width Bi: 10 - 50mm
bend radius R: 28 - 48mm
pitch: 20mm

e-chain®, to be filled in the outer radius
Series E14

Series E14

inner height hi: 19mm
inner width Bi: 15 - 50mm
bend radius R: 28 - 125mm
pitch: 30.5mm

e-chain®, to be filled in the outer radius
Series E200

Series E200

inner height hi: 24.3mm
inner width Bi: 57mm
bend radius R: 55 - 200mm
pitch: 46mm

e-chain®, to be filled in the outer radius
Series E200.2

Series E200.2

inner height hi: 24.3mm
inner width Bi: 37+37/50+50mm
bend radius R: 55 - 200mm
pitch: 46mm

e-chain®, to be filled in the outer radius
E16

Series E16

inner height hi: 32mm
inner width Bi: 23 - 100mm
bend radius R: 40 - 100mm
pitch: 30.5mm

e-chain®, to be filled in the outer radius
Series E26

Series E26

inner height hi: 36.5mm
inner width Bi: 75mm
bend radius R: 63 - 250mm
pitch: 56mm

e-chain®, to be filled in the outer radius
Series E26.2

Series E26.2

inner height hi: 37.1mm
inner width Bi: 48+48mm
bend radius R: 63 - 250mm
pitch: 56mm

e-chain®, to be filled in the outer radius
Series E26.3

Series E26.3

inner height hi: 37.1mm
inner width Bi: 47+48+47mm
bend radius R: 63 - 250mm
pitch: 56mm

e-chain®, to be filled in the outer radius
Series E300

Series E300

inner height hi: 48.5mm
inner width Bi: 75mm
bend radius R: 75 - 300mm
pitch: 67mm

e-chain®, to be filled in the outer radius
Series E300.2

Series E300.2

inner height hi: 48.5mm
inner width Bi: 48+48mm
bend radius R: 75 - 300mm
pitch: 67mm

e-chain®, to be filled in the outer radius
Series E300.3

Series E300.3

inner height hi: 48.5mm
inner width Bi: 47+46+47mm
bend radius R: 75 - 300mm
pitch: 67mm

e-chain®, to be filled in the outer radius
E045

Series E045

inner height hi: 9.4mm
inner width Bi: 10 - 16mm
bend radius R: 18 - 38mm
pitch: 13mm

e-chain®, to be filled in the outer radius
Series E045.2

Series E045.2

inner height hi: 9.4mm
inner width Bi: 7+7mm | 9+9mm
bend radius R: 18 - 38mm
pitch: 13mm

e-chain®, to be filled in the outer radius
Series E045.3

Series E045.3

inner height hi: 9.4mm
inner width Bi: 9+9+9mm
bend radius R: 18 - 38mm
pitch: 13mm

e-chain®, to be filled in the outer radius
E06

Series E06

inner height hi: 10.7mm
inner width Bi: 10 - 20mm
bend radius R: 18 - 38mm
pitch: 20mm

e-chain®, to be filled in the outer radius
Series E065

Series E065

inner height hi: 11.3mm
inner width Bi: 16mm
bend radius R: 18 - 38mm
pitch: 15mm

e-chain®, to be filled in the outer radius
Series E065.2

Series E065.2

inner height hi: 11.3mm
inner width Bi: 9+9mm
bend radius R: 18 - 38mm
pitch: 15mm

e-chain®, to be filled in the outer radius
Series E065.3

Series E065.3

inner height hi: 11.3mm
inner width Bi: 9+9+9mm
bend radius R: 18 - 38mm
pitch: 15mm

e-chain®, to be filled in the outer radius
Series E065.4

Series E065.4

inner height hi: 11.3mm
inner width Bi: 9+9+9+9mm
bend radius R: 18 - 38mm
pitch: 15mm

e-chain®, to be filled in the outer radius

Version "Z" can be filled from the inside

Series Z045

Series Z045

inner height hi: 9.4mm
inner width Bi: 16mm
bend radius R: 18 - 38mm
pitch: 13mm

e-chain®, to be filled in the inner radius
Series Z045.2

Series Z045.2

inner height hi: 9.4mm
inner width Bi: 7+7mm
bend radius R: 18 - 38mm
pitch: 13mm

e-chain®, to be filled in the inner radius
Series Z26

Series Z26

inner height hi: 36.5mm
inner width Bi: 75mm
bend radius R: 63 - 250mm
pitch: 56mm

e-chain®, to be filled in the inner radius
Series Z26.2

Series Z26.2

inner height hi: 37.1mm
inner width Bi: 48+48mm
bend radius R: 63 - 250mm
pitch: 56mm

e-chain®, to be filled in the inner radius
Series Z26.3

Series Z26.3

inner height hi: 37.1mm
inner width Bi: 47+48+47mm
bend radius R: 63 - 250mm
pitch: 56mm

e-chain®, to be filled in the inner radius
Series Z300

Series Z300

inner height hi: 48.5mm
inner width Bi: 75mm
bend radius R: 75 - 300mm
pitch: 67mm

e-chain®, to be filled in the inner radius
Series Z300.2

Series Z300.2

inner height hi: 48.5mm
inner width Bi: 48+48mm
bend radius R: 75 - 300mm
pitch: 67mm

e-chain®, to be filled in the inner radius
Series Z300.3

Series Z300.3

inner height hi: 48.5mm
inner width Bi: 47+46+47mm
bend radius R: 75 - 300mm
pitch: 67mm

e-chain®, to be filled in the inner radius
Z06

Series Z06

inner height hi: 10.5mm
inner width Bi: 10 - 20mm
bend radius R: 18 - 38mm
pitch: 20mm

e-chain®, to be filled in the inner radius
Series Z065.3

Series Z065.3

inner height hi: 11.3mm
inner width Bi: 9+9+9mm
bend radius R: 18 - 38mm
pitch: 15mm

e-chain®, to be filled in the inner radius
Z08

Series Z08

inner height hi: 14.6mm
inner width Bi: 10 - 50mm
bend radius R: 28 - 48mm
pitch: 20mm

e-chain®, to be filled in the inner radius
Series Z14

Series Z14

inner height hi: 19mm
inner width Bi: 15 - 50mm
bend radius R: 28 - 125mm
pitch: 30.5mm

e-chain®, to be filled in the inner radius
Series ZF14

Series ZF14

inner height hi: 21mm
inner width Bi: 38mm
bend radius R: 28mm
pitch: 30.5mm

Series Z200

Series Z200

inner height hi: 24.3mm
inner width Bi: 57mm
bend radius R: 55 - 200mm
pitch: 46mm

e-chain®, to be filled in the inner radius
Series Z200.2

Series Z200.2

inner height hi: 24.3mm
inner width Bi: 37+37/50+50mm
bend radius R: 55 - 200mm
pitch: 46mm

e-chain®, to be filled in the inner radius
Series Z16

Series Z16

inner height hi: 32mm
inner width Bi: 23 - 100mm
bend radius R: 40 - 125mm
pitch: 30.5mm

e-chain®, to be filled in the inner radius

e-chain® selection guide

Selection aids

Assembly instructions

Assembly instructions

Application examples

easy chain

easy chain: "E" and "Z" make things "easy"

  • Easy to fill from inside ("Z" version) and outside ("E" version)
  • Easy filling without opening and closing the lids
  • Can be joined and separated at "any point"
  • Cost-effective single-piece chain
  • Dirt-repellent outer contour
  • Mounting brackets with integrated strain relief available
  • Limited torsional movement possible
  • Available with interior separation (many types)
  • Flammability class UL94-V2
  • Suitable for cleanrooms applications

Typical industries and applications

  • General machinery
  • Clean room application
  • Electronic equipment
  • Office furniture
  • Vending machines
  • Packaging machines

Certifications


IPA certificate: standard material
ISO Class 2 in accordance with the standard ISO 14644-1, v = 1m/s

UL94-V2 classifications

easy chain with special igumid ESD material as an electrically conductive version available upon request
